Designed to increase your productivity
As a creative professional, time’s rarely on your side. That’s why Wacom Cintiq Pro puts productivity solutions right at your fingertips.
Description
Create directly on screen with our most natural pen experience
Use the Wacom Cintiq Pro 24* for absolute harmony with your work. Premium 4K screen with world class color performance, and virtually no parallax, enhance every creative breakthrough. The Wacom Pro Pen 2 provides state-of-the-art creative pen technology, meaning every stroke, every move of your hand is followed with unerring accuracy.
Live.Dare.Create.
Wacom Pro Pen 2:
|
|
|---|---|
| Our state-of-the-art creative pen technology. 8,192 levels of pressure sensitivity and unparalleled tilt recognition means that every stroke, every move of your hand is followed with unerring accuracy. | |
|
4x more pressure sensitive* |
4x more accurate* |
|
Virtually no lag |
Natural tilt support |
|
No parallax |
No batteries or recharging |
| *Compared to Wacom Pro Pen | |
A display that looks, and feels, totally natural
The etched glass screen provides a distinct, tactile experience as you draw, mimicking the feel of a pen on paper. And with minimized parallax, and a screen strong enough to resist ‘pooling’ and rippling, each mark appears precisely where you expect it, every time.
Connect your way
Connect to any Mac or PC with a single USB-C cable (included) to a USB-C port for both video and data. DisplayPort or HDMI are also included, which require USB port for data.
Make it match you
The ExpressKey™ Remote puts 17 programmable buttons within easy reach. The on-screen keypad and the radial menus offer further one-touch shortcuts.
A natural interface
Pan, zoom or rotate your work with multi-touch gestures* - as simple as using your smartphone.
*available on Wacom Cintiq Pro 24 touch model
Ideas jump off the screen
4K resolution (3840 x 2160 px) is packed into a 24” LCD display with superb color accuracy (99% of Adobe® RGB). You can see every tiny detail of your greatest artwork, design or photographic projects.
- Product Type: Creative Pen Display 24
- Model Number: DTH-2420
- Display Size: 677 x 394 x 47 mm (26.65 x 15.5 x 1.9 in)
- Display weight: 7.2 kg (15.87 lbs) without optional stand
- Screen Size: (Measured Diagonally) 59.94 cm / 23.6 in
- Technology: IPS UHD high brightness panel
- Displayable Colors (maximum) : 1.07 billion colors (10 bits color)
- Aspect Ratio: 16:9
- Viewing Angle: 176° (88°/88°) H, (88°/88°) V
- Contrast Ratio: 1000:1
- Brightness: 350 cd/m2
- Response Rate: 14 ms
- Active Area: 522 X 294 mm (20.55 X 11.57 in)
- Color Gamut: 99% Adobe RGB
- Industry Standard Pre-sets: 6500° K whitepoint default
- Graphics Input: USB type C port (supporting DisplayPort Alternate Mode) or DisplayPort or HDMI 2.0 port (required for 3840 x 2160 resolution)
- Multi-touch: Yes - on touch model only (DTH-2420)
- Pen: Wacom Pro Pen 2
- Pressure Levels: 8192, both pen tip and eraser
- Tilt Range: 40 degrees
- Tilt Recognition:±60 levels
- Type Pressure-sensitive, cordless, battery-free
- Switches: Tip switch, 2 side switches, eraser
- Nibs: 10 (6 standard, 4 felt) in pen stand
- Pen Box/Holder: Yes - Pen Holder
- Pen Stand: Yes
- Grip: Latex-free silicone rubber
- Technology: Patented electromagnetic resonance method
- Resolution: 5080 lpi
- Expresskeys™: 17 customizable, application-specific on, included ExpressKey™ Remote
- Touch Ring: Yes - on included ExpressKey Remote
- Touch Strips: No
- Rocker Ring And Home Button: Yes - on included ExpressKey Remote
- Radial Menu: Yes
- Precision Mode: Yes
- Display Toggle: Yes
- Dedicated Pan, Scroll, Zoom, Brush Size: Yes
- ExpressKey™ Remote Dimensions: 135 x 52 x 10 mm (5.3 x 2.0 x 0.4 in)
- ExpressKey™ Remote Continuous Operation: Up to 160 hours, if a key is pressed every 30 seconds
- ExpressKey™ Remote Charge Time: Up to 2 hours
- Cables Included: USB to USB cable (3m), DisplayPort to DisplayPort cable (3m), HDMI 2.0 to HDMI 2.0 cable (3m),USB-C to USB-C cable (1.5m), DisplayPort to Mini DisplayPort adapter, microUSB to USB cable (30 cm; for ExpressKey Remote)
- PC and Mac Connection Requirements: USB-C supporting DisplayPort Alternate Mode (DP Alt), or DisplayPort and standard USB-A, or HDMI port and standard USB-A port
- Ports included: 4 x USB3 ports* 1 x USB C port , 1 x HDMI2.0 port , 1 x DP port , 2 USB-A Ports (one for ExpressKey Remote dongle) *When connected to host computer over USB-C (including Cintiq Pro Engine), Cintiq Pro USB 3.0 ports run at USB 2.0 speeds to accommodate 4K video bandwidth over USB-C.
- Audio: Audio headset jack, built-in microphone
- Power Supply Input: 100 to 240 VAC, 50/60HZ
- Power Supply Output 20 VDC, 2.25 A (max)
- Power Consumption: Power ON mode (Max.): 100 W , Power sleep mode: 2.0 W or lower , Power OFF mode: 0.5 W or lower
- Battery: Rechargable Li-ion battery on include ExpressKey Remote
- Security: Kensington® Lock Port (lock purchased separately)
- System Requirements: PC: Windows® 7 or later (latest service pack/build), Mac: OS X 10.11 or later (latest update); USB-C port with DisplayPort Alternate Mode (UHD), or Mini DisplayPort/DisplayPort (UHD) and USB-A, or HDMI 2.0 (UHD) and USB-A; Internet access for driver download.
- What's Included: Wacom Cintiq Pro 24 or Wacom Cintiq Pro 24 touch,Wacom Pro Pen 2 with 4-color pen ring set, ExpressKey™ Remote (with USB-A RF dongle and 30cm micro-USB to USB charger cable), Pen stand with 10 replacement nibs (6 standard, 4 felt) and nib removal tool, Pen holder, 180W AC adaptor and 1.8m power cable, 1.5m USB-C to USB-C cable, 3m DisplayPort to DisplayPort cable, 3m HDMI2.0 to HDMI2.0 cable, 3m standard USB-A to USB-A cable, DisplayPort to Mini DisplayPort adapter, Quick Start Guide, Regulation sheet, Cleaning cloth
- Certifications: VCCI Class B, FCC Part 15 Subpart B (class B) and C, CE, IC ICES-003 and 210, RCM, KCC, BSMI, C-tick, CB, CCC, GOST-R, China RoHS, Korean RoHS, EU RoHS
- Additional Accessories: Wacom Ergo Stand, Wacom Cintiq Pro Engine, Wacom Color Manager, Wacom Pro Pen 3D, Wacom Keyboard, Replacement Wacom nibs (standard and flex) for Wacom Pro Pen 2, Additional previous generation pens (Classic, Airbrush, Art, Pro Pen), Replacement ExpressKey Remote, Replacement Wacom Pro Pen 2
- Limited Warranty 1 year in Hong Kong
Specifications are subject to change. Specification numbers like display size, active area and weight are approximate
